ORIA Mini will work with practically all Audio interfaces and Speakers on the Market. Below you can find more information about connecting your equipment to ORIA Mini's inputs and outputs.
Input
ORIA Mini can accept audio input either via Stereo Line inputs or via a Digital Optical port.
The Line inputs are balanced and can accept signal levels up to +18dBU. The topology of the inputs means it can also accept unbalanced inputs via a 1/4" TS cable, allowing you to receive audio from audio interfaces or hardware that have unbalanced RCA outputs.
The optical port of ORIA Mini accepts stereo S/PDIF audio up to 96kHz via a TOSlink connector. If the device being plugged into ORIA Mini outputs S/PDIF via a coaxial connector, then an external coaxial to TOSlink converter should be used.
Output
The speaker outputs of ORIA Mini are balanced TRS connections, which can be plugged directly into the TRS or XLR inputs found on most Studio Monitors.
In addition, an unbalanced 1/4" TS connection can also be used to connect ORIA Mini to speakers or amplifiers with unbalanced inputs, such as an RCA input.
